Overview:
GCC series modules are ball screw driven linear actuators, embedded within the guide rails, , designed for projects with light loads and limited space usage. with ISO Class 5 clean-room level.
Basic info:
Drive Type: Ball screw driven type, close type
Stroke: max 1250mm
Characteristics:
Ball screw precision option
- Equipped with a standard rolled ballscrew,with an optional ground ball screw available
Cleanroom certification info
- Improved design of the steel strip and carriage, no-contact and no wear design.
- Equipped with a standard air connector, with optional negative pressure dust extraction
- AFF cleanroom-specific grease is applied
ISO clean room class 5
- The product has been tested by the SGS organization and conformsto ISO Class 5(0.1μm、0.2μm、0.3μm and 0.5μm)
Simple Assembly
- Positioning holes are provided at the bottom.
- The screws can be installed from the bottom up without removing the steel cover.
Flexible Motor Collocation
- To increase the flexibility of the machine design, alternative motor brands, powers, and mounting directions can be chosen as needed.
Integrated Oil Injection Hole
- By using an external integrated oil injection hole design,all linear blocks can be lubricated at once without the need for disassembly maintenance.
Industry:
- Automated Production Line — Precision assembly, machine tool processing, heavy-duty material handling
- Semiconductor Equipment — Wafer dicing, chip packaging, precision inspection
- Medical Devices — Surgical robots, imaging equipment, precision injection
- Optical Instruments — Laser processing, optical inspection, precision focusing
- New Energy Industry — Battery electrode forming, photovoltaic module welding
- 3C Manufacturing — Smartphone assembly, precision dispensing, screen inspection
- Scientific Instruments — Experimental platform positioning, precision measurement equipment
- Military & Aerospace — Missile guidance, aircraft component machining
