Overview
YSO is a ball – screw driven linear actuator series. It corresponds to TOYO’s ETH series from Taiwan, known for its precision – oriented design in the electromechanical field.
Basic Info
- Model Numbers: YSO135, YSO170, YSO220
- Repeat Positioning Accuracy: ±0.005mm
- Stroke and Speed: The maximum stroke length is 1.5m, and the highest operating speed is 1m/s
- Screw Driven Type: High – precision, suitable for limited – length applications
Characteristics
- Load – Balanced Design: With a load – balanced ball screw and linear guide, it can handle various loads, speeds, and moments, ensuring smooth operation.
- Motor Compatibility: Can match motors from different brands and models, adjusting driving force as required, eliminating the need for a reducer.
- High Rigidity: The integral processing of the structure and body provides high rigidity, and the special cam – curve design ensures smooth movement.
- Motor Connection: Offers connection types like MS (Unit + coupling + motor) and ML/MR/MD (Unit + connect part + motor)
Industry Applications
YSO is applicable in industries such as LCD panel manufacturing, photovoltaic industry, white goods production lines, and lithium battery manufacturing, where high – precision linear motion is required.
