RLO 220

Question 1

Q: What professional certificates do you have？

Answer

A: We pay great attention with the quality of our products and we have many quality certificates: ISO9001, ISO14001, CE European Union certification certificate, ROHS certificate etc.

Question 2

Q: Can I get a sample?

Answer

A: Yes, sample is available. If you are interested, you can contact us by e-mail ([email protected]) to get more photos and information.

Question 3

Q: Delivery Date?

Answer

A: Normal order delivery of linear motion products is generally controlled within 1-2 months.
Normal order delivery for linear unit and higher precision products is generally controlled within 7-15 working days.

Question 4

Q: What is your shipping optional?

Answer

A: Our cooperating transportation companies include DHL, TNT, UPS, etc. Sea transportation, air transportation and express delivery are all available. If you have a specific carrier, please let us know when you place the order.

Question 5

Q: Whether to accept customized products?

Answer

A: You can contact us by e-mail ([email protected] ) and we will recommend the most suitable project according to your requirements.

Question 6

Q: What is your payment methods?

Answer

A: T/T in advance.

Question 7

Q: Which countries do you have distributor?

Answer

A: LIMON agent in Asia: Singapore, Japan, India
LIMON agent in Europe: Hungary, Turkey, Israel
LIMON agent in South America: Brazil

Question 8

Q: Where is your main market?

Answer

A: LIMON do quite well in Europe, Asia and South America, also China is a potential market for us. Now LIMON’s distributors have covered more than 32 country and regions.

Question 9

Q: Can I be a LIMON agent?

Answer

A: We are really looking forward to having you as a solid partner of LIMON. Please contact us by e-mail ([email protected] ) , we can start talk and get to know more about each other.

Technical Parameters	Type		RLO220-C1	RLO220D2-C1	RLO220-C2	RLO220D2-C2
	Driving Method		Linear Motor Driven Type With Iron Core
	Repetitive Accuracy		±2μm
	Strength	X-X	20μm/300mm
		Y-Y	20μm/300mm
	Max load		60 kg		120 kg
	Max Speed		4 m/s
	Max Accelerated Speed		4G
Technical Parameters	Peak Current		9.6 Arms		19.2Arms
	Continuous Current		3.6 Arms		7.2Arms
	Peak Thrust		900N		1800N
	Continuous Thrust		340N		680N
	Interphase Resistance		7.5Ω		3.9Ω
	Interphase Inductance		42.3 mH		21.5 mH
	Maagnetic Pole Distance		24mm
Basic Specification	Standard Stroke		100-4500 mm/100 pitch
	Max Outline of Main Engine’s Cross Section		220*105
	Home Sensor		PM-Y45(NPN)

RLO220

RLO 220

RLO Series
