Characteristics:
- High Speed: The maximum operating speed can reach 12,000 rpm, which is double the speed of a regular servo.
- High Precision: With built-in high-precision trajectory tracking algorithms, it offers high dynamic response and significantly enhances trajectory tracking performance. It supports 17-bit to 23-bit single-turn/multi-turn absolute encoders, greatly improving equipment positioning accuracy.
- High Efficiency: Smooth operation enhances processing speed, increasing production efficiency.
- High Synchronization: With high synchronization characteristics, it comes with a distributed clock module. Its synchronization jitter is in the sub-microsecond level, with jitter error within 1 μs, meeting the requirements of various on-site multi-axis synchronous control.
- High-speed communication: The entire series adopts higher-performance main control chips, further enhancing communication and interaction capabilities.
- Control Performance: Using a new ARM+FPGA architecture, the control delay is minimized, the current loop response bandwidth reaches up to 3KHz, achieving faster command following, and effectively shortens the setting time for accurate positioning.The servo drive performance featuring ultra-high speed and ultra-precision control will give greater play to the mechanical equipment performance.
- Automatic Gain Turning: Equipped with two automatic tuning loop parameter functions, “Single Parameter” and “Auto- Turning “, greatly reducing servo tuning time and significantly improving usability.
- Enhanced Vibration Suppression: Equipped with enhanced vibration suppression function, incorporating four resonance suppression filters, second-order torque low-pass filters, input shaping filters, and position notch filters, capable of perfectly addressing vibration issues across low-frequency, mid-frequency, and high-frequency bands.
