- Linear Motor Driven -
MLO Series
MLO110
Classification: MLO Series
Drive type: Linear motor driven type with iron core
Repetitive accuracy: ±2μm
Maximum outline size of main section: 110*96mm
Space saving design
High Stiffness
Heavy load capacity
Suited for small space and heavy load working condition
| Techinical Parameters | Type | MLO110-C1 | MLO110D2-C1 | MLO110C2 | MLO110D2-C2 |
| Driving Method | Linear Motor Driven Type With Iron Core | ||||
| Repetitive Accuracy (μ) | ±2 μm | ||||
| Continuous Thrust (N) | 120N | 240N | |||
| Max Thrust (N) | 240N | 480N | |||
| Max Accelerated Speed (M/S2) | 4G | ||||
| Max Speed (MM/S) | 4000 | ||||
| Basic Specification |
Standard Stroke (mm) | 100-4500 mm / 100 pitch | |||
| Max Outline of Main Engine's Cross Section | 110 x 96 | ||||
| Home Sensor | PM-T45(NPN) | ||||
MLO135
Classification: MLO Series
Drive type: Linear motor driven type with iron core
Repetitive accuracy: ±2μm
Maximum outline size of main section: 135*96mm
Space saving design
High Stiffness
Heavy load capacity
Suited for small space and heavy load working condition
| Techinical Parameters | Type | MLO135-C1 | MLO135D2-C1 | MLO135C2 | MLO135D2-C2 |
| Driving Method | Linear Motor Driven Type With Iron Core | ||||
| Repetitive Accuracy (μ) | ±2 μm | ||||
| Continuous Thrust (N) | 240N | 480N | |||
| Max Thrust (N) | 480N | 1200N | |||
| Max Accelerated Speed (M/S2) | 4G | ||||
| Max Speed (MM/S) | 4000 | ||||
| Basic Specification |
Standard Stroke (mm) | 100-4500 mm / 100 pitch | |||
| Max Outline of Main Engine's Cross Section | 135x 96 | ||||
| Home Sensor | PM-Y45(NPN) | ||||
