    KS 40

    Single Axis Stages

    KS 40

    Single Axis Stages
    Classification: Open type
    Drive type: Ball screw drive
    Sealed type: General environment, semi-sealed
    Repetitive accuracy: ±0.005mm
    Strong carrying capacity
    High-speed transplanting
    Easy assembly and operation

    Quote Now

      [email protected]

      Quick Help: Contact one of our experts and we'll get back to you in 24 hours!

      Download Catalog

      Code Ball Screw Linear Guide
      Nominal Outside Diameter (mm) Lead(mm) Basic Dynamic Rated Load (N) Basic Static Rated Load (N) Basic Dynamic Rated Load (N) Basic Static Rated Load (N) Permissible Static Moment
      Pitching Deflection Rolling
      Slide Block A Slide Block S Slide Block A Slide Block S Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2 Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2 Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2
      KS40D01 P 8 1 1243 2794 3920 / 6468 / 33 182 / / 33 182 / / 81 162 / /
      C 1130 2540
      KS40D05 P 8 5 1177 2145
      C 1070 1950
      Code Length of Rail (mm) Repetitive Accuracy (mm) Traveling Parallesiam Max.Driving Torque
      P C P C P C
      KS40D 100 ±0.003 ±0.01 0.01 / 1.2 0.8
      150
      200



      Frequently Asked Questions

      A: We pay great attention with the quality of our products and we have many quality certificates: ISO9001, ISO14001, CE European Union certification certificate, ROHS certificate etc.

      A: Yes, sample is available. If you are interested, you can contact us by e-mail ([email protected]) to get more photos and information.

      A: Normal order delivery of linear motion products is generally controlled within 1-2 months.
      Normal order delivery for linear unit and higher precision products is generally controlled within 7-15 working days.

      A: Our cooperating transportation companies include DHL, TNT, UPS, etc. Sea transportation, air transportation and express delivery are all available. If you have a specific carrier, please let us know when you place the order.

      A: You can contact us by e-mail ([email protected] ) and we will recommend the most suitable project according to your requirements.

      A: T/T in advance.

      A: LIMON agent in Asia: Singapore, Japan, India
      LIMON agent in Europe: Hungary, Turkey, Israel
      LIMON agent in South America: Brazil

      A: LIMON do quite well in Europe, Asia and South America, also China is a potential market for us. Now LIMON’s distributors have covered more than 32 country and regions.

      A: We are really looking forward to having you as a solid partner of LIMON. Please contact us by e-mail ([email protected] ) , we can start talk and get to know more about each other.
