| Technical Parameters |
Type |
GLC-50 |
GLC-50D2 |
|
|
Driving Method |
Linear Motor Driven Type With Iron Core |
|||
|
Repetitive Accuracy |
±2μm |
|||
|
Strength |
X-X |
20μm/300mm |
||
|
Y-Y |
20μm/300mm |
|||
|
Max load |
5 kg |
|||
|
Max Speed |
4 m/s |
|||
|
Max Accelerated Speed |
4G |
|||
| Technical Parameters |
Peak Current |
3.4Arms |
||
|
Continuous Current |
1.1Arms |
|||
|
Peak Thrust |
150N |
|||
|
Continuous Thrust |
50 N |
|||
|
Interphase Resistance |
24.6Ω |
|||
|
Interphase Inductance |
70.2 mH |
|||
|
Maagnetic Pole Distance |
20mm |
|||
| Basic Specification |
Standard Stroke |
50-1650 mm/50 pitch |
120-1520 mm/100 pitch |
|
|
Max Outline of Main Engine’s Cross Section |
55×60 |
|||
|
Home Sensor |
PM-Y45(NPN) |
|||
