Caractéristiques :
- Haute vitesse : The maximum operating speed can reach 12,000 rpm, which is double the speed of a regular servo.
- Haute précision : With built-in high-precision trajectory tracking algorithms, it offers high dynamic response and significantly enhances trajectory tracking performance. It supports 17-bit to 23-bit single-turn/multi-turn absolute encoders, greatly improving equipment positioning accuracy.
- High Efficiency: Smooth operation enhances processing speed, increasing production efficiency.
- High Synchronization: With high synchronization characteristics, it comes with a distributed clock module. Its synchronization jitter is in the sub-microsecond level, with jitter error within 1 μs, meeting the requirements of various on-site multi-axis synchronous control.
- High-speed communication: The entire series adopts higher-performance main control chips, further enhancing communication and interaction capabilities.
- Control Performance: Using a new ARM+FPGA architecture, the control delay is minimized, the current loop response bandwidth reaches up to 3KHz, achieving faster command following, and effectively shortens the setting time for accurate positioning.The servo drive performance featuring ultra-high speed and ultra-precision control will give greater play to the mechanical equipment performance.
- Automatic Gain Turning: Équipé de deux fonctions de réglage automatique des paramètres de la boucle, “Single Parameter” et “Auto-Turnning“, réduisant considérablement le temps de réglage du servo et améliorant de manière significative la facilité d'utilisation.
- Suppression améliorée des vibrations : Équipé d'une fonction améliorée de suppression des vibrations, incorporant quatre filtres de suppression de la résonance, des filtres passe-bas de couple de second ordre, des filtres de mise en forme d'entrée et des filtres coupe-bande de position, capables de traiter parfaitement les problèmes de vibration dans les bandes de basse, moyenne et haute fréquence.
